AG11 Series Silage Defacers
- Cutting teeth create better feed and less waste
- Patent-pending tooth design
- Clean, non-obstructive framing gives clear evident
Features
Expand All
Collapse All
Frontier™ AG11 cutting teeth
Cutting teeth
Open frame provides visibility
Cutting teeth create better feed and less waste
Frontier™ AG11 cutting teeth
The cutting edges completely blend the silage, prevent sizing particles, and decrease spoilage by reducing the amount of oxygen that reaches the silage. This creates better feed and reduces waste.
Patent-pending tooth design strikes the perfect depth
Cutting teeth
The depth-of-cut adjustment allows better mixing of the feed from top to bottom based on individual feeding requirements.
Adjustments can be made for different types of feed like high-moisture corn, haylage, or corn silage. The tooth sections are also replaceable, allowing for extended use of the entire implement.
Clean, non-obstructive framing gives see-through visibility
Open frame provides visibility
The hydraulic motor and drive system are located inside the defacer's frame, which adds to the visibility and longevity of the Frontier™ AG11 Series.
Specifications
Specs & Compare
Add Model
Specs & Compare |
||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John DeereAG11 SeriesSilage Defacers |
Dimensions
| Height | 61 cm 24 in. |
|||
|---|---|---|---|---|
| Length | 141 cm 55.5 in. |
|||
| Width | 243.8 cm 96 in. |
|||
| Cutting width | 243.8 cm 96 in. |
Weight
| Operational | 376.5 kg 830 lb |
|||
|---|---|---|---|---|
| Shipping | 421.8 kg 930 lb |
Attachment carriers
| Current series style | Skid steer |
|---|
Compatibility
| Skid steer SAE operating capacity (ROC) | 793.8 kg 1,750 lb |
|---|
Cutting tooth
| Type | Non-sizing | |||
|---|---|---|---|---|
| Replaceable | Yes |
Bearing
| Type | Greasable |
|---|
Motor
| Chain type, ASAE | 80 | |||
|---|---|---|---|---|
| Shaft | 3.8 cm 1.5 in. |
Warranty
| Time period | 1 year |
|---|
Additional information
| Date collected |
|---|
Key Specs
| Current series style | ||||
|---|---|---|---|---|
| Cutting tooth | ||||
| Cutting width |
